P2 Series Ultrasonic Pneumatic Welding Machine

The P2 series ultrasonic pneumatic welding machine is a digitally upgraded industrial welding device designed for medium and high-precision welding scenarios. Featuring four intelligent welding modes and full-digital frequency tracking, it solves the frequency drift problem of traditional ultrasonic welders and delivers stable, repeatable, zero-trace welding for plastics, electronics, fabrics and industrial assembly lines.

product details

Product Overview

The P2 Series Ultrasonic Pneumatic Welding Machine is an upgraded digital industrial welding device, specially optimized for medium and high-precision industrial welding scenarios. Equipped with four professional intelligent welding modes, it achieves full-scene coverage and precise welding adaptation for diversified production demands. Empowered by advanced digital frequency tracking and tuning technology, the equipment intelligently locks and optimizes the operating frequency in real time, effectively eliminating the frequency drift and instability defects of traditional ultrasonic welding machines. With ultra-fast millisecond-level response speed, the whole welding process is highly stable, consistent, and reliable. Adopting a standardized pneumatic driving structure and visualized digital pressure display design, it realizes accurate parameter control and repeatable welding effect, perfectly meeting the standardized, high-precision, and high-stability production requirements of consumer electronics, plastic parts, daily necessities, and industrial accessories.

Core Advantages

• Four Intelligent Welding Modes, Full-Scene Adaptation

Built-in four professional customized welding modes covering time welding, energy welding, power triggering and force triggering. It freely switches according to product material, size and process standards, realizing one machine for multiple purposes and meeting diverse precision welding requirements of different workpieces.

• Digital Automatic Frequency Tracking, No Frequency Drift

Adopts upgraded full-digital frequency tracking technology, which monitors and corrects the operating frequency in real time during operation. It effectively solves the frequency instability, weak welding and inconsistent finished product problems of traditional equipment caused by temperature change, voltage fluctuation and workpiece difference.

• Millisecond-Level Rapid Response, Stable Welding Process

Ultra-fast millisecond-level response speed realizes instantaneous start and stop of welding. The welding force, time and ultrasonic output are precisely matched, avoiding virtual welding, missing welding and unstable welding strength, ensuring every batch of products with uniform and reliable welding quality.

• Visual Digital Pressure Control, High Repeatability

Equipped with high-precision digital pressure display function, no need for external sensors. Real-time viewing and precise adjustment of welding pressure parameters support standardized parameter recording and process tracing, greatly improving production consistency and yield.

• Pneumatic Driving & Low Failure Rate

Stable pneumatic transmission structure features uniform pressure output, low operation noise and durable performance. It supports long-term continuous industrial operation, reduces manual intervention and maintenance costs, and improves overall production efficiency.

• Zero-Trace Welding, No Damage to Product Appearance

Low-pressure and instantaneous molecular fusion welding technology leaves no indentation, deformation or residual marks on the workpiece surface. It protects the original appearance and texture of products, suitable for high-standard finished product processing.

Technical Specifications

Parameter

Specification

Parameter

Specification

Model

P2 Series

Frequency

20KHz / 35KHz / 40KHz (optional)

Power

800W – 2600W

Pressure

0.05 – 0.7 MPa adjustable

Welding Stroke

30 – 75 mm

Trigger Mode

Time / Energy / Power / Force

Pressure Display

Digital numeric

Frequency Tracking

Full-digital auto

Response Time

≤ 5 ms

Driver Type

Pneumatic

Welding Area

Φ 5 – 100 mm

Machine Weight

65 – 120 kg (by spec)

Control Panel

7-inch HMI / button dual-mode

Working Cycle

1 – 3 s / piece (typical)

Input Power

AC 220V 50/60Hz

Cooling

Fan-cooled

Four Intelligent Welding Modes

The P2 series integrates four switchable intelligent welding modes to precisely match different workpiece materials, sizes and process requirements. The comparison table below helps you quickly select the most suitable mode.

Mode

Trigger Logic

Best For

Typical Application

Time Welding

Trigger by preset welding duration

Stable workpiece, consistent material

Standard plastic parts

Energy Welding

Trigger by preset ultrasonic output energy

Slight material / thickness variation

Mixed-batch production

Power Triggering

Trigger when ultrasonic power reaches threshold

Precise power consistency required

Electronic precision parts

Force Triggering

Trigger by real-time welding force feedback

Sensitive workpiece, zero-trace required

Appearance parts / gift crafts

P2 vs Ordinary Pneumatic Welding Machine

Compared with traditional analog pneumatic welding machines, the P2 series delivers significant upgrades in frequency control, parameter visualization and welding precision. The table below summarizes the key differences.

Feature

Ordinary Pneumatic Welder

P2 Series

Frequency Tracking

Manual / analog tuning

Full-digital auto, real-time

Pressure Display

Analog gauge

Digital numeric, real-time adjustable

Response Speed

50 – 200 ms

≤ 5 ms

Welding Modes

Single time mode only

Time / Energy / Power / Force

Frequency Drift

Frequent, requires re-tuning

Effectively eliminated

Process Traceability

Not supported

Parameter recordable

Batch Consistency

±15 – 25 %

±3 – 5 %

Appearance Protection

Indentation / scald risk

Zero-trace welding

Working Principle

The P2 series ultrasonic pneumatic welding machine converts electric energy into high-frequency ultrasonic vibration energy through an intelligent ultrasonic generator. Combined with stable pneumatic pressure drive, the equipment acts on the workpiece contact surface. Relying on advanced digital frequency tracking technology, it automatically locks the optimal resonant frequency, and completes rapid molecular fusion welding within milliseconds. The four switchable intelligent welding modes realize precise control of welding time, energy and pressure, ensuring stable, accurate and high-strength welding effect for different workpieces.

Application Scope

Consumer electronics precision parts, plastic structural parts, household appliance accessories, textile non-woven fabrics, webbing stitching, daily plastic products, gift crafts, medical small parts, auto plastic auxiliary parts, and medium and high-precision batch welding production scenarios requiring parameter visualization and quality traceability.

Typical Industries

• Consumer Electronics — Mobile phone parts, earphone charging case, smart wearable housing, button assembly.

• Plastic Parts — ABS / PP / PC / PA assembly, filter housing, daily plastic products.

• Textile & Webbing — Non-woven fabrics, webbing stitching, strap welding, fabric lamination.

• Auto Accessories — Interior plastic auxiliary parts, sensor housing, wire harness clips.

• Medical & Craft — Medical small parts, gift crafts, stationery assembly.

Selection Guidance

When choosing between ultrasonic welding machines, evaluate your workpiece material, precision requirement, batch size and whether you need process traceability. The P2 series is recommended if you need stable frequency, visual pressure control, and appearance-friendly zero-trace welding. For desktop or small-area spot welding, you may also refer to our desktop ultrasonic spot welding machine.

FAQ

Q1: What is the core advantage of the P2 series compared with ordinary pneumatic welding machines?

A: The P2 series upgrades digital frequency tracking technology and visualized pressure display, with four intelligent welding modes and millisecond-level response. It solves the frequency instability problem of traditional equipment, with higher welding accuracy, better stability and stronger production traceability, making it more suitable for high-standard batch production.

Q2: Can this machine adapt to different material welding?

A: Yes. Multiple intelligent welding modes and adjustable digital parameters support welding of various thermoplastic materials, fabrics and synthetic materials, with strong scene compatibility and flexible parameter matching.

Q3: Will ultrasonic pneumatic welding damage product appearance?

A: No. Adopting low-pressure instantaneous molecular fusion technology, the welding process is stable and controllable, with no extrusion deformation, no high-temperature scald and no surface residue, realizing zero-trace high-precision welding.

Q4: How do I choose between Time / Energy / Power / Force welding modes?

A: For stable materials and standard workpieces, choose Time mode; for slight material or thickness variation, choose Energy mode; when high power consistency is required, choose Power mode; for appearance parts that need zero-trace welding, choose Force mode.

Q5: Is on-site installation and training supported?

A: Yes. We provide installation guidance, parameter setting support and operator training videos. For batch orders, on-site engineer commissioning is available — please contact our sales team in advance.

Contact Us

Machine Power On：Press the power switch button to start the welding machine.

Starting Method：Press the start switch with both hands.

Welder Reset：

Manual Operation Mode: Press and hold the two operating switches until the machine reaches the ready state and output is enabled.

Automatic Operation Mode: The welder requires an external input signal, which is provided by an external source.

System Composition：System operation requirements depend on the system type, selected options, the user’s equipment and system interfaces, as well as the specific application.

Control Process：The control of the welding process depends on the system structure. For generators equipped with a color front-panel display, users can control the welding process using the IGWA software operated through the HMI.

Quick Mold Change：In production scenarios involving multiple mold types, the One-Button Mold Change technology reduces labor costs and improves production efficiency.

Online Function：The MES system can identify and collect data from each welding operation, including output power, welding stroke, and welding time (connection to MES requires a pre-customized interface).

Pressure Test with Digital Display：Air pressure shown digitally.

Partners

details showcase

Product Parameters

Machine Maintenance

Ultrasonic generator : Wipe the machine body regularly with a clean, soft cloth to remove dust and stains, and prevent foreign objects from entering the interior and affecting performance . Check whether the wiring connections are loose, ensure good ventilation and heat dissipation, and prevent malfunctions caused by overheating.

Transducer and amplitude transformer : Check for cracks and wear, and ensure the connections are secure. Replace or tighten any faulty components promptly.

Welding head maintenance : Clean surface residue after each use, regularly check for wear, and replace it in time if the wear is severe to ensure welding effect.

Control system : Regularly check whether the control buttons and display screen are working properly to avoid accidental operation, and update the system software in a timely manner.

Regular inspections : The overall performance of the equipment is tested at regular intervals, such as welding strength and frequency stability, to ensure that the equipment is in optimal working condition.

After-Sales Service

Our warranty period is 1 year, and if you have any other questions, we will provide you with online technical support to help you.
